EOTECH Commercial Low Power ATPIAL BLK

EOTECH Commercial Low Power ATPIAL BLK

The Advanced Target Pointer/Illuminator/Aiming Laser (ATPIAL) is small, lightweight and easy to use. The aiming system has integrated infrared and visible aiming lasers and an infrared illuminator. The ATPIAL (AN/PEQ-15) has been battle-tested for use on small arms and crew-served weapons. The ATP-000-A18Vis is a visible only model that was created to support tactical training requirements for law enforcement and military organizations.

Product Details

• Length/Width/Height: 4.6" x 2.8" x 1.6" (117 mm x 71 mm x 41 mm)
• Weight: 7.5 oz with batteries
• Battery Power: One 3-volt DL123 battery
• Visible Aim Laser - ATPIAL
  • Output: 4.0 mW (Class IIIa)
  • Beam Divergence: 0.5 mrad
  • Wavelength: 605-665 nm
  • Range: > 25 m
• IR Aiming Laser - ATPIAL
  • Output Power Low: 0.6 mW (Class I)
  • Output Power High: 25 mW (Class IIIb)
  • Beam Divergence: 0.5 mrad
  • Wavelength: 820-850 nm
  • Range: > 600 m (Low), 2000 m (High)
• IR Illuminator - ATPIAL
  • Output Power Low: 3.5 mW (Class IIIa)
  • Output Power High: 30 mW (Class IIIb)
  • Beam Divergence: 1-105 mrad (minimum)
  • Wavelength: 820-850 nm
  • Range: > 2,000 m
• Danger: Laser Radiation
  • Avoid direct exposure to beam
• IR Laser
  • Power: 50 mW
  • Wavelength: 830 nm
  • Class IIIb
• VIS Laser
  • Power: < 5 mW
  • Wavelength: 650 nm
  • Class IIIa
