AGM WLAD 1TAN Multi-Spectral Weapon Laser Aiming Device (Class 1) TAN

Overview

The AGM WLAD Weapon Laser Aiming Device is a Class 1 multi-spectral laser system with a green visible aiming laser, near-infrared (near-IR) / IR aiming laser, IR illuminator, and a 300 lm LED illuminator.

Features

• Rapid active target acquisition
• True night vision compatible mode
• Six function modes
• User selectable constant wave or pulsed flashlight modes
• 300 lumen LED flashlight
• Tactical remote switch
• Co-boresighted aiming lasers
• Mounting: Weaver or Picatinny (MIL-STD-1913)
• Low base design
• IPX8 / IP68 waterproof rated
• 2-year warranty

Specs (highlights)

• Class: IR laser, green laser, IR illuminator — Class 1
• Wavelength: IR 830 ± 15 nm, Green 520 ± 10 nm
• Operating distance: IR laser > 400 m; Green laser > 25 m (direct sunlight); IR illuminator > 100 m
• Output power: IR laser < 0.2 mW; Green laser < 1 mW; IR illuminator < 1 mW
• Divergence: IR 0.5 ± 0.3 mrad; Green 0.5 ± 0.3 mrad; IR illuminator 1–100 mrad
• Battery: One 18650 Li-Ion rechargeable battery (3.7V)
• Shockproof: 1,200 G
• Weight: 298 g (10.5 oz)
• Dimensions: 113 × 77 × 42 mm

Included

• Aiming/Illumination Module
• Remote Switch
• Operation Manual
• Soft Carrying Case
• Clean Brush
• Clean Cloth
